Cable clip for Linear Fluorescent Lampholders
品番:
26.927.E302-0
EAN:
4049853
-
0,6 - 1,0
製品情報 "Cable clip for Linear Fluorescent Lampholders"
- For cable with insulation: ø 2±0,1 mm (e.g. cable 0.5 mm², with PVC insulation)
- Cable clip with integral retention
- Capacity: max. 7 cables
- IP 40
- Cable clip with integral retention
- Capacity: max. 7 cables
- IP 40
| Ausführung: | Accessories for Linear Fluorescent Lampholders |
|---|---|
| Cable holder: | Cable clip |
| Color: | white |
| Luminaire wall thickness: | 0.6 - 1.0 |
| Material: | Material: PC |
| Note warranty conditions: | *Warranty conditions of BJB GmbH & Co. KG as stated as available via the Internet under https://www.bjb.com/en/legal-information/general-terms-and-conditions/ are valid. |
| Packaging quantity: | 1000 |
| Producttype: | Accessories for Linear Fluorescent Lampholders |
| Series: | Linear Fluorescent Lampholders for dry rooms (IP20) |
| Weight: | 2 g |
| mounting method 1: | Push-in pins |
| old article number: | 26.927.-302.50 |
利用可能なダウンロード
Available CAD Downloads
